Items purchased through Cisco Outlet are remanufactured. Conditions may vary from the visual depictions on the site.
AIR-ANT2524V4CR-RF
2.4GHz2dBi/5GHz4dBiCeilngMountOmniAnt4ptRPTNC REMANUFACTURED
Inventory quantities are subject to availability and are not guaranteed until the order is placed.
The AIR-ANT2524V4CR is a Cisco Aironet four-element, MIMO, dual-band ceiling-mount omnidirectional antenna designed for indoor environments. It operates in the 2.4 GHz and 5 GHz frequency ranges and features:
Frequency range: 2.400 to 2.484 GHz and 5.150 to 5.850 GHz
Gain: 2 dBi at 2.4 GHz and 4 dBi at 5 GHz
Polarization: Linear
Azimuth 3-dB beamwidth: Omni-directional
Elevation 3-dB beamwidth: 69 degrees at 2.4 GHz and 60 degrees at 5 GHz
Antenna connector: 4 RP-TNC male connectors
Cable length: 36 inches (91 cm), plenum rated
Dimensions: 7.25 x 7.25 x 1 inches (18.4 x 18.4 x 2.5 cm)
Mounting: Ceiling mount
Operating temperature range: -20°C to 60°C (-4°F to 140°F)
Weight: Approximately 1.3 oz
This antenna is suitable for use with Cisco Aironet and Catalyst wireless access points and is designed to provide reliable dual-band coverage in indoor ceiling-mounted deployments.
| Application | Indoor |
| Dimensions (WxDxH) | 7.2 in x 1 in x 7.2 in |
| Directivity | Omni-directional |
| Frequency Range | 2.4 GHz, 5 GHz |
| Gain | 2 dBi (for 2.4 GHz), 4 dBi (for 5 GHz) |
| Placing / Mounting | Ceiling mountable |
| Product Type | Antenna |
