MGBSX1-RF
Cisco Small Business MGBSX1 - SFP (mini-GBIC) transceiver module - GigE
Inventory quantities are subject to availability and are not guaranteed until the order is placed.
The MGBSX1 is a Cisco Small Form-Factor Pluggable (SFP) transceiver module designed for multimode fiber (MMF) connections. It supports 1000BASE-SX Ethernet at a speed of 1000 Mbps (1 Gbps) with a typical wavelength of 850 nm. The maximum transmission distance for the MGBSX1 is up to 500 meters. It uses a duplex LC connector type.
Key specifications of the MGBSX1:
Media Type: Multimode fiber (MMF)
Speed: 1000 Mbps (1 Gbps)
Maximum Distance: 500 meters
Wavelength: 850 nm (Tx and Rx)
Connector: Duplex LC
Typical Applications: 1000BASE-SX Ethernet connections over multimode fiber
Power Consumption: Approximately 1W max
Operating Temperature: 0º to 70ºC
Dimensions: Approximately 13.4 x 8.5 x 56.5 mm
This module is hot-pluggable and is commonly used in Cisco Small Business and enterprise switches that support SFP modules, enabling flexible fiber optic connectivity options.
| Cabling Type | 1000Base-SX |
| Data Link Protocol | Gigabit Ethernet |
| Data Transfer Rate | 1 Gbps |
| Device Type | SFP (mini-GBIC) transceiver module - LC |
| Form Factor | Plug-in module |
| Cabling Type | 1000Base-SX |
| Compatible Slots | 1 x SFP (mini-GBIC) |
| Connectivity Technology | Wired |
| Data Link Protocol | Gigabit Ethernet |
| Data Transfer Rate | 1 Gbps |
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Interfaces | 1 x Ethernet 1000Base-SX - LC x 2 |
