SFP-10G-LR-RF
10GBASE-LR SFP Module REMANUFACTURED
Inventory quantities are subject to availability and are not guaranteed until the order is placed.
The Cisco SFP-10G-LR is a 10 Gigabit Ethernet SFP+ transceiver module designed for long-range communication over single-mode fiber (SMF). Here are its key features:
Data Rate: 10 Gbps
Form Factor: SFP+
Reach: Up to 10 kilometers on standard single-mode fiber (G.652)
Connector Type: Duplex LC (PC or UPC)
Wavelength: Approximately 1310 nm
Transmitter Type: DML (Distributed Feedback Laser)
Receiver Type: PIN photodiode
Power Consumption: Approximately 1 watt
Operating Temperature Range: 0 to 70°C (standard models)
Optical Standard: IEEE 10GBASE-LR
Compatibility: Supports 10G Ethernet links for switches and other networking devices
Additional Variants: There are industrial temperature range versions (e.g., SFP-10G-LR10-I) and extended temperature range versions (e.g., SFP-10G-LR-X) that support the same 10 km reach with enhanced environmental tolerance.
This module is widely used for connecting switches and other network components over long distances with reliable 10G performance on single-mode fiber infrastructure
| Cabling Type | 10GBase-LR |
| Data Link Protocol | 10 Gigabit Ethernet |
| Data Transfer Rate | 10 Gbps |
| Designed For | Catalyst Switch Module 3012 for IBM BladeCenter, Switch Module 3110G for IBM BladeCenter, Switch Module 3110X for IBM BladeCenter; Nexus 5010 |
| Device Type | SFP+ transceiver module - LC/PC single mode |
| Dimensions (WxDxH) | 0.5 in x 2.2 in x 0.4 in |
| Form Factor | Plug-in module |
| Manufacturer Warranty | 90 days warranty |
| Max Transfer Distance | 6.2 miles |
| Optical Wave Length | 1310 nm |
| Cabling Type | 10GBase-LR |
| Compatible Slots | 1 x SFP+ |
| Compliant Standards | IEEE 802.3ae |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 Gigabit Ethernet |
| Data Transfer Rate | 10 Gbps |
| Depth | 2.2 in |
| Designed For | Cisco Catalyst Switch Module 3012 for IBM BladeCenter, Switch Module 3110G for IBM BladeCenter, Switch Module 3110X for IBM BladeCenter |
| Device Type | SFP+ transceiver module |
| Form Factor | Plug-in module |
| Height | 0.4 in |
| Interfaces | 1 x Ethernet 10GBase-LR - LC/PC single mode x 2 |
| Max Operating Temperature | 158 |
| Max Transfer Distance | 6.2 miles |
| Min Operating Temperature | 32 |
| Optical Wave Length | 1310 nm |
| Service & Support | Limited warranty - 90 days |
| Weight | 2.65 oz |
| Width | 0.5 in |
