SFP-10G-LR-X-RF
10GBASE-LR SFP Module for Extended Temp range REMANUFACTURED
Inventory quantities are subject to availability and are not guaranteed until the order is placed.
The Cisco SFP-10G-LR-X is a 10GBASE-LR SFP+ transceiver module designed for extended temperature range operation. It supports a link length of up to 10 kilometers on standard single-mode fiber (SMF, G.652) using a 1310 nm wavelength with a duplex LC connector. This module is multirate and supports 10GBASE-LR, 10GBASE-LW, and OTU2/OTU2e standards. It features a transmit power range of -8.2 to +0.5 dBm and a receive power range of -14.4 to +0.5 dBm, using NRZ DSP technology. The module is compatible with various Cisco Catalyst switches and network modules, including the Catalyst 9300 Series and C9300-NM-8X network module. The extended temperature range makes it suitable for environments requiring more robust thermal performance.
Key Features:
Type: 10GBASE-LR SFP+ transceiver, multirate
Wavelength: 1310 nm
Fiber Type: Single-mode fiber (SMF, G.652)
Connector: Duplex LC
Maximum Link Length: 10 km
Operating Temperature: Extended temperature range (eTemp: -5 to 85 °C)
Transmit Power: -8.2 to +0.5 dBm
Receive Power: -14.4 to +0.5 dBm
Standards Supported: 10GBASE-LR, 10GBASE-LW, OTU2/OTU2e
DSP Technology: NRZ
Compatibility: Cisco Catalyst 9300 Series Switches, C9300-NM-8X network module
This module is ideal for long-distance 10 Gigabit Ethernet connections in environments requiring extended temperature tolerance.
| Cabling Type | 10GBase-LR |
| Data Link Protocol | 10 Gigabit Ethernet |
| Data Transfer Rate | 10 Gbps |
| Device Type | SFP+ transceiver module - LC/PC single mode |
| Dimensions (WxDxH) | 0.5 in x 2.2 in x 0.4 in |
| Form Factor | Plug-in module |
| Manufacturer Warranty | 90 days warranty |
| Max Transfer Distance | 6.2 miles |
| Optical Wave Length | 1310 nm |
| Cabling Type | 10GBase-LR |
| Compatible Slots | 1 x SFP+ |
| Compliant Standards | IEEE 802.3ae |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 Gigabit Ethernet |
| Data Transfer Rate | 10 Gbps |
| Depth | 2.2 in |
| Device Type | SFP+ transceiver module |
| Form Factor | Plug-in module |
| Height | 0.4 in |
| Interfaces | 1 x Ethernet 10GBase-LR - LC/PC single mode x 2 |
| Max Operating Temperature | 185 |
| Max Transfer Distance | 6.2 miles |
| Min Operating Temperature | 23 |
| Optical Wave Length | 1310 nm |
| Service & Support Details | Limited warranty - 90 days |
| Service & Support | 90 days warranty |
| Weight | 2.65 oz |
| Width | 0.5 in |
